Brand Name : | Penta Laser |
Model Number : | BULL 16035 |
Delivery Time : | 50 Days Upon Receipt of Payment |
Price : | Negotiable |
Supply Ability : | 2000 Sets per Year |
Large Format Metal Fiber Laser Cutting Machine For Mild Steel Stainless Steel 3000W to 6000W
Featrues
Penta BULL Series fiber laser cutting machine have advantage of power saving, lower power consumption which is just 20%-30% compared to backpack CO2 Laser Cutting Machine.
Fast moving, adopt imported CNC and control software, YASKAWA servo motor which is more simple and convenient for operation.
Fast cutting, adopt imported intelligent cutting head and some other high-level system to guarantee the stability and advancement.
Fast piercing and the production efficiency is promoted more than 50%.
Lower running and maintenance cost
Environmental protection, acquire laser protection function and
suction system which guarantee operator's health and safty
Gantry design with double drive structure, high damping machine
tool with better rigidity which can stand higher speed and
acceleration speed.
The rack and guide is comprehensively sealed to prevent the
friction without oil and dust pollution in order to make the drive
system much longer service time and ensure the movement precision
of the machine tool.
Specification
Specification | Model |
BULL 16035 | |
Table Travel | 4m~30m Customized |
Mechanical Accuracy(VDI 3441) | ±0.12mm/m |
Mechanical Repeatability | ±0.1mm/m |
Rapid Speed | 70m/min |
Maximum Acceleration | 0.6G |
Z Travel | 200mm |
Laser Power Option | 3000W-6000W |
Application
Penta BULL series Fiber Laser Cutting Machine mainly for cutting metallic material such as mild steel, stainless steel, aluminum alloy, titanium alloy, high temperature alloy ect. for sheet metal processing, aviation, aerospace, electronics, electrical appliances, tube fittings, automobile, food machinery, engineering machinery, precision parts, shipbuilding, metallurgical equipment, elevators, household appliances, craft gifts, tool processing, decoration, advertising and other manufacturing industries.
![]() |
