Double Servo Motor Driver IPG Laser Cutting Machine Pallet Exchange Automatical

    Buy cheap Double Servo Motor Driver IPG Laser Cutting Machine Pallet Exchange Automatical from wholesalers

    Buy cheap Double Servo Motor Driver IPG Laser Cutting Machine Pallet Exchange Automatical from wholesalers
    • Buy cheap Double Servo Motor Driver IPG Laser Cutting Machine Pallet Exchange Automatical from wholesalers

    Double Servo Motor Driver IPG Laser Cutting Machine Pallet Exchange Automatical

    Ask Lasest Price
    Brand Name : Penta Laser
    Model Number : BOLT 4025
    Price : Negotiable
    Supply Ability : 2000 Sets per Year
    Delivery Time : 50 Days Upon Receipt of Payment
    • Product Details
    • Company Profile

    Double Servo Motor Driver IPG Laser Cutting Machine Pallet Exchange Automatical


    IPG Laser Source Pallet Exchange Stable Fiber Laser Cutting Machine


    Bolt Series is Penta's high end series for customers that demands extremely high performance and efficiency.

    Sheet metal laser cutting has many advantages that has led to great results. High accuracy is one of the most important ones. This allows the laser to cut off unlimited and complex shapes, clean cutting that requires little or no finishing and generating a minimum amount of heat. All this in short processing times and with optimum processing quality. PENTA laser has proven itself in a wide range of industries including automotive manufacturing, aerospace, light-fixture, kitchen ware, stainless steel, decorative maerials, case and cabinet ect. In the broad industrial application of laser technology, PENTA plays a decisive role in most fields.


    Features


    -IPG RAYCUS Laser Source 1kw to 12kw at your choice

    -Auto Focus Cutting Head dedicated for high power (Precitec)

    -Dedicated laser CNC that makes the best and most of the laser

    -Fast pallet exchanger and full enclosure

    -Double servo motor driven synchronously, bring higher speed and acceleration

    -Double driving synchonous technology make sure high speed and precision cutting

    -Handy embedded cutting database


    Technical Specification


    ModelBOLT 4025
    Rate output power2400 W
    Rapid Speed180 m/min
    Maximum Acceleration2.2 G
    Accuracy±0.03 mm/m
    Mechanical Repeatability±0.01 mm/m
    Maximum cutting thickness of mild steel18 mm
    Maximum cutting thickness of stainless steel8 mm
    Working Table4000 mm ×2500 mm

    Advantages


    Efficient Control System

    New Z32 real time CNC system, with dynamic and geometric JERK control. The date exchange between CNC system and machine drive system is adopted with fiber and power modulation for the ultimate cutting quality in the corners

    Imported Operating System Smart Manager

    Smart Manager is originally imported from Europe. This software is based on the Windows
    XP system and can fully interface with Italy CNC system which original imported. Therefore the real control of the machine, the laser source and software update is more convenient and fast.

    Stable Mainframe

    The base consists of foundation, working table, beam,slider, ram, cooling system,pneumatic system,
    suction system,dross cleaner, enclosure and so on.

    Imported nesting software function

    Based on AUTO CAD/CAM automatic program nesting software and easy to use, Multilayer nesting function to intensively increase the sheet usage rate

    Pre-perforation System

    Accomplish the pre-perforation as settled


    Samples
