    Moderately Thin Sheet Fiber Laser Cutter IPG TRUMPF RAYCUS Cabinet Article Laser Cutting

    Ask Lasest Price
    Brand Name : Penta Laser
    Model Number : SWING 3015
    Delivery Time : 50 Days Upon Receipt of Payment
    Price : Negotiable
    Supply Ability : 2000 Sets per Year
    • Product Details
    • Company Profile

    Moderately Thin Sheet Fiber Laser Cutter IPG TRUMPF RAYCUS Cabinet Article Laser Cutting


    Moderately Thin Sheet Fiber Laser Cutter IPG TRUMPF RAYCUS Cabinet Article Laser Cutting


    Introduction


    Penta SWING Series fiber laser machine is an economic option to the market for its efficiency and stability at an affordable cost; it’s an idea choice for sheet metal owners for its low operational cost and production flexibility compare to conventional processing methods. Though an entry level machine, it’s powered by the same professional laser CNC as with our high power laser machines, easy for laser beginners to learn and various handy and practical functions for advanced users.



    Features


    - 1KW-3KW IPG / TRUMPF / RAYCUS laser source at choice

    - Full enclosure for operator’s safety

    - Gantry structure, double servo motor driven for high speed and acceleration

    - Fast pallet exchanger

    - Embedded professional cutting database

    - Dimension:3m*1.5m/4m*2m/6m*2m/

    - Professional nesting software


    Specification


    ModelSWING 3015
    Table Travel3000mm X 1500mm
    Rapid Speed120m/min
    Acceleration1.1G
    Mechanical Accuracy+ 0.05mm/m
    Repeatability+ 0.03mm/m
    Power Range1000W2000W3000W
    Cutting Capacity

    M.S: 10mm

    S.S: 4-5mm

    M.S: 18mm

    S.S: 8mm

    M.S: 20mm

    S.S: 10mm

    Working TableAutomatic Pallet Exchanger

    Standard Cutting Head

    Cutting head from RAYTOOLS, Switzerland is a simple, yet flexible design to optimize the processing head to the end user’s Fiber Laser. The head is capable of cutting a wide range of materials and delivers both user-friendly operation and reliable performance at an attractive price.


    § Optimization of flexible optical configuration and smooth and efficient air flow design can choose different clear aperture lens;

    § Focus adjusted, scope for 16 mm;

    § Draw-out lens seat, which is easy and simple to protect the lens and replacement;

    § Smooth assist gas flow;

    § Compact, lightweight design;

    § Models available for most popular fiber connections;

    § Double water cooling structure design.


    Cutting head adopts flexible design, competent of collision-proof and high-reflective plate cutting, which automatically stops cutting and flexibly diverges and resets when accidental collision occurs, meanwhile with nozzle fitting built-in annular conditioning and side structure, can also has thick plate explosion-proof control sputter function, making the whole cutting process free from effect.


    Application


    Mainly for cutting metallic material such as mild steel, stainless steel, aluminum alloy, titanium alloy, high temperature alloy ect.
